3t sling chain, double stranded, length 134cm, fork head hook, SC22, 01267

Description

3000 kg sling chain, length 134 cm, fork head hook with safety latch, double stranded, SC22.3T.1M – 01267

The application field of this sling chain is pulling heavy loads in horizontal direction with winches. It has proven itself under the hardest conditions countless times.

Technical data:

Pulling capacity:                                                                   3000 kg

Opening width of the hook in the area of the safety latch:   27 mm

Inner opening width of the hook:                                          43 mm

Length of the hook:                                                              160 mm

Fork head hook with spring loaded safety latch

Inner dimensions of the big eyelet at the end of the chain:  76 mm x 150mm

Total length:                                                                           134 cm

Strength of the chain links:                                                    10 mm

Chain links are welded

Weight:                                                                                  7.8 kg
Shipping weight:                                                                    8.5 kg

For any inquiries please don’t hesitate to contact us by phone at the following number: +49 2162 / 353967.
Customer pickup is possible after consultation.
